Common Cathode 10 Pin 2 Bit 0.98 x 0.75 x 0.31 Inch 0.55" Red LED Display 2pcs

Price:   $8.99 $0.90

  • Model: 551463
  • 1000 Units in Stock

Please Choose:

(complete orders today,deliverd around 02/06/2024)
  • Shipping time
    About 5-7 days.
  • means of transportation
    EMS,TNT,UPS,DHL,FEDX,HK AIR
  • Payment
    Credit Card
  • Email us
    [email protected]
  • New Products
    1 Pc, Drill America 5/8" Carbide 4 Flute Single End Long End Mill, MMO5/8-4FSE-LONG
    $125.90 $12.59 Save: 90% off
    Paint Brushes Flat Edge 0.43" Width Bristle with Wood Handle 10Pcs - Black - 0.43" x 0.16"
    $14.49 $1.45 Save: 90% off
    M6x44mm Male Thread Knurled Clamping Knobs Grip Thumb Screw on 2Pcs - Black,Silver Tone
    $9.10 $0.91 Save: 90% off
    3M P95 Paint Spray and Pesticide Application Particulate Filter 5000/6000-Series White 10 pk
    $39.49 $3.95 Save: 90% off
    • Details
    Details:
  • Product Name: 7 Segment LED Digital Display Tube; Type: Common Cathode; Model: 5621AH; Application: Widely used in home appliances, instruments, car accessories, etc. Also good for DIY and experiment
  • Common Cathode: 8-7; Digital Display: 2 Digit; Digital Number: 2 Bit 7 Segment; Emitted Color: Red
  • Pin Number: 10; Continuous Forward Current: 20mA; Average Forward Voltage: 2V; Power Consumption: 36mW. Convenient to use, it can be driven under such low voltage, low current conditions.
  • Luminous Intensity: 11mcd; Number Height: 0.55 inch; Panel Size: 25 x 19 x 8mm / 0.98" x 0.75" x 0.31" (L*W*H); Total Size: 25 x 19 x 14.5mm / 0.98" x 0.75" x 0.57" (L*W*H)
  • Material: Plastic, Metal; Color: Black, White; Package Content: 2 x LED Digital Display Tubeļ¼›Notice: It is recommended to use constant current not constant voltage, constant voltage will cause uneven brightness.

  • Used widely in home appliances, instruments, accessories, etc.

    specifications
    Product Name : LED Digital Display Tube
    Type : Common Cathode
    Model : 5621AH
    Common Cathode : 8-7
    Digital Display : 2 Digit
    Digital Number : 2 Bit 7 Segment
    Emitted Color : Red
    Pin Number : 10
    Continuous Forward Current : 20mA
    Average Forward Voltage : 2V
    Power Consumption : 36mW
    Luminous Intensity : 11mcd
    Number Height : 0.55 inch
    Panel Size : 25 x 19 x 8mm / 0.98 x 0.75 x 0.31 inch (L*W*H)
    Total Size :  25 x 19 x 14.5mm / 0.98 x 0.75 x 0.57 inch (L*W*H)
    Material : Plastic, Metal
    Color : Black, White
    Package Content : 2 x LED Digital Display Tube
  • Country of Origin: China
