3.5X-180X Double Boom Simul Focal Trinocular Stereo Microscope 38MP Video Digital USB Microscopio Camera Phone PCB Repair Tools

3.5X-180X Double Boom Simul Focal Trinocular Stereo Microscope 38MP Video Digital USB Microscopio Camera Phone PCB Repair Tools Description

3.5X-90X Extremely Large Zoom Magnification PowerTrinocular Design for High Quality Photo, USB PC and CCD Video ImagingErect Stereo Sharp Images Over a SUPER Widefield of ViewAccurate Alignment Ensuring Fatigue-Free Long Time ViewingCrystal Clear Original True Color Images45 Inclined Trinocular Head with SUPER Widefield High-Eyepoint Eyepieces30mm SUPER Widefield Eyepieces (see the difference in the above picture)Both Ocular-Tubes with Adjustable DiopterAdjustable Interpupillary DistanceFull Optical Glass ElementsPrecise Ground Glass Lenses4" (100mm) Extremely Large Working DistanceVersatile Boom Stand Covering Large Working AreaDouble-Arm Design for 3-Degree FreedomAble to Place Microscope Head Toward to Any DirectionHeavy-Duty Cast Steel Stand Finished with Stain Resistant EnamelRugged Solid Cast Steel Base30mm SUPER Widefield Eyepieces Included165mm and 30mm working distance auxiliary objective
Head: 45 inclined 360 swiveling trinocularEyepiece: 30mm super widefield high-eyepoint WF10X/20mmObjective: 0.35-9.0XAuxiliary objective :SZM0.5X & SZM2.0XZoom Range: 6.4:1Diopter Adjustment: 5dpInterpupillary Distance: 2-3/16" - 2-15/16"(55-75mm)Field of View: 2-1/2" (65mm) in diameterWorking Distance: 4" (100mm)Boom Stand: 20" double-arm (overall length: 30"), 17" high pillar, 10-1/4"x8-1/4"x2-0" solid cast steel base
POWER/MODE:This camera is plug-in to power on, long press the button for 3 secondsto power off, then short press for 1 second to power on. Power onsuccess if you hear ticking with red indicator light on. After power on,short press for 1 second to change to video mode, press one moresecond to change to picture/video playback mode, one more pressback to camera mode.MENU?Short press the button for 1 second and enter menu setting page. UseUP/DOWN button to select related funtions and press OK button toenter submenu.a) Chinese/English language settings: use UP/DOWN button to selectand press OK button to confirm;b) Grid line settings: press UP/DOWN to select line and press OK button to enter, press UP/DOWN to open/close 10 grid lines rulers, to open/close 8 grid lines, every lines direction, position, color or width, then press OK to change the lines direction, position, color or width. Press MENU button again to return to upper level menu;c) Exposure setting: press UP/DOWN to select auto/manual exposure mode, then press OK to confirm;d) EV settings: under auto exposure mode, enter to select +-0.3/0.7/1.0/1.3/1.7/2.0 exposure value as needed;e) White balance settings: can select auto, manual or one-button-calibration mode after entering, there might be color deviation if you change the light, then you can put a white paper and select one-button-calibration to calibrate the color. You can also adjust the red and green value manually for special use;f) Color setting: can select colorful or white/black mode as needed;g) Light frequency settings: can select 50Hz/60Hz as needed;h) Acutance settings: options for strength/standard/soft;i) Contrast settings: high/middle/low options as needed;j) Video size: 3 options for 2K24fps/1080P60fps/720P60fps can be used as needed;k) Mirror function: vertical/horizonal mirror functions in option;l) Format: it can be used for new card or even defected card before taking photos in memory;m) Regain default settings: regain all your settings to original default settings;n) System information: its original software version, repress MENU button to exit;OK/CAPTURE/RECORD:Under camera mode, short press OK button to take a photo; under videomode, short press to start or stop recording; under MENU mode, itsconfirm button, for lines open/close and vertical/horizonal change,position adjust, and also line color/width change.UP/+: under camera mode, short press this button to increase EV.DOWN/-: under camera mode, short press this button to decrease EV.HDMI-Compatible Interface: connect camera to a monitor with HDMI-Compatible interface,please use 16:9 wide monitor.USB/PC Interface:1. connect the camera to your computer with USB cable, then power on,if a SD card available in camera, then you will enter U disk mode and can prereview the pictures/videos from camera SD card or copy to your computer.2. If no SD card in camera, you will enter PC-CAM mode to view pictures from your computer directly, and no driver needed here.Note: DC/12V interface is for camera with 5V-12V/1A input power adapter, and unsuited adapters cant be used, otherwise the camera will be burned broken then
144 bright white LED bulbs100,000 hours of lifeIntense and focused shadow-free illuminationThe brightness of 0-100%Adjustable,high brightnessVariable intensity controlPower input: 100-240V, 50-60HZSuit for the dia of the lens: 30mm-63mm
Package list:
1X Trinocular Stereo Zoom Head1X Pair of Super Widefield High-Eyepoint WF10X Eyepieces
1X Pair of Super Widefield High -Eyepoint WF10X Eyepieces1X 0.5X auxiliary objective WD 165 mm1X2.0X auxiliary objective WD 30 mm1X Protection glass1X Double-Arm Boom Stand1X Focus Rack1X Pair of Eye-Guard1X144PCS Led Light
1X CTV1/2 Adapter
1X 38MP Camera (following up the option you selection)
1X HDMI -Compatible Cable

Details
